Technical Specifications
|
Axis Travel & Maximum Positioning Speed |
X & U Axis Max. Speed | 5000mm & 130mtr/min |
| Y Axis Max. Speed | 1400mm & 80mtr/min | |
| Z Axis Max. Speed | 100mm & 80mtr/min | |
| V Axis Max. Speed | 900mm & 130mtr/min | |
| W Axis max. Speed | 100mm & 40mtr/min | |
| A Axis Max. Speed | 950mm & 35mtr/min | |
| Boring Head Configuration | Vertical Drill Bits Top | 9 drill |
| Vertical Drill Bits Bottom | 9 drill | |
| Horizontal Drill Bits | 2(L)+2(R) 2(F)+2(B) | |
| Boring Head Speed | 2800 RPM | |
| Motor Power | 2.2Kw*2 | |
| Spindle Configuration | Spindle Power | 3.5Kw*2 |
| Spindle Speed | 18000 RPM | |
| Processing Size Range | Max. Width of Panel | 1200 mm |
| Min. Width of Panel | 50 mm | |
| Max. Length of Panel | 5000 mm | |
| Min. Length of Panel | 250 mm | |
| Max. Thickness of Panel | 48 mm | |
| Min. Thickness of Panel | 12 mm | |
| Other Parameters | Total Power | 18.9 Kw |
| Working Voltage | 380V/50Hz | |
| Working Pressure | 0.7-0.8Mpa | |
| Approx Weight | 2500Kg | |
| Overall Size | 6480x2840x2200 mm |
