Technical Specifications
| Max. Load/Pressure Rating | 120 Ton |
| Platen Size | 2500 x 1300 x 42 mm |
| No of Platen | 2 nos |
| Opening Between Layers | 350 mm |
| No. of hydraulic Cylinders | 6 nos |
| Size of Hydraulic Cylinders | 90 x 125 mm |
| Heating Power | 18 (9+9) kw |
| Hot Oil Delivery Pump Power | 1 hp |
| Hydraulic Pump Power | 5 hp |
| Total Power | 23.5 Kw |
| Machine Dimension(LxBxH) | 3650 x 1650x 2500 mm |
| Weight | 6000kg approx |
