Technical Specifications
| Max. Load/Pressure Rating | 160 Ton |
| Platen Size | 2500 x 1300 x 42 mm |
| No of Platen | 4 nos |
| Opening Between Layers | 100 mm |
| No. of hydraulic Cylinders | 8 nos |
| Size of Hydraulic Cylinders | 90 x 125 mm |
| Heating Power | 36(9+9+9+9) kw |
| Hot Oil Delivery Pump Power | 2 hp |
| Hydraulic Pump Power | 7.5 hp |
| Total Power | 43 Kw |
| Machine Dimension(LxBxH) | 3650 x 1650x 2500 mm |
| Weight | 8000kg approx |
